DEKO DKA Series IGBT Inverter Arc Electric Welding Machine 220V MMA Welder for Welding Working and Electric Working
Production Description
DEKO Gipower RU Store
Specifications
Power Voltage: AC 1-230V±15%
Rated Input Capacity: 5.8 KVA
Efficiency: 85%
Duty Cycle: 60%
Insulation Degree: F
Current Range: 20-200A
DKA Series 220V Inverter Arc Welding Machine
The device is easy to weld stainless steel, alloy steel, carbon steel, copper, copper alloy and other non-ferrous metal, even for the first time welder. IGBT power device with unique control mode make the device Start ARC easily, Stable Welding ARC, Deep Weld Pool and Beautiful Welding Shape, perfect for the home DIY and general repairing work. In addition, IGBT technology makes devices smaller and lighter. This makes it easy to transport so you can weld wherever and whenever you need.
Special Features
DEKO Gipower RU Store
Household Smart Welder
Compact and exquisite MMA welder, made of heavy duty stainless steel body, painted with durable paints, ensure its long-last serving life-span
Adjustable Welding Current
The newly added digital display can accurately show the current data during operation and provide reliable support for your welding operation(Available on model DKA-160, DKA-160G,DKA-200G,DKA-250)
Advanced IGBT Performance
Inverter frequency is 20KHz, and reduce the volume and weight of the machine.Start ARC easily, Stable Welding ARC, Deep Weld Pool and Beautiful Welding Shape
Energy Saving
Reduce the damage of copper and lron， obviously increase the welding frequency， and energy-conserving result is remarkable
Complimentary Necessities
Built-in high performance fans to help heat dissipation. Standard EU ground cord and automatic thermal safety protection. Comes with a brush w/ chipping hammer as a gift
Compare to different sets
DEKO Gipower RU Store
Model
DKA-120
DKA-160
DKA-200
Power Voltage(V)
AC 1-230±15%
AC 1-230±15%
AC 1-230±15%
Rated Input Capacity(KVA)
4.1
5.0
5.8
Efficiency(%)
85
85
85
Power Factor(cosφ)
0.93
0.93
0.93
No Load Voltage(V)
60
60
60
Current Range(A)
20-120(±5)
20-160(±5)
20-200(±5)
Duty Cycle(%)
40
40
40
Usable Electrodes(ømm)
1.6-3.2
1.6-3.2
1.6-4.0
Insulation Degree
F
F
F
Protection Degree
IP21S
IP21S
IP21S
*Includes
(1) DKA-120 Welder, (1) Electrode Clamp, (1) Ground Clamp, (1) A Brush with Chipping Hammer
(1) DKA-160 Welder, (1) Electrode Clamp, (1) Ground Clamp, (1) A Brush with Chipping Hammer
(1) DKA-200 Welder, (1) Electrode Clamp, (1) Ground Clamp, (1) A Brush with Chipping Hammer
Item DIM(mm)
203x92x125
220x100x160
238x109x163
Package DIM(mm)
300x115x200
320x130x280
350x130x260
N.W
2.37
2.4
2.84
G.W
3.37
3.4
4.04
Tips: If you need welding mask or welding glove. Please click here ( or ). And we will send correct adapter free according to your country.
Model
DKA-160G
DKA-200G
DKA-250
Power Voltage(V)
AC 1-230±15%
AC 1-230±15%
AC 1-230±15%
Rated Input Capacity(KVA)
5.0
5.8
6.8
Efficiency(%)
85
85
85
Power Factor(cosφ)
0.93
0.93
0.93
No Load Voltage(V)
60
60
60
Current Range(A)
20-160(±5)
20-200(±5)
20-250(±5)
Duty Cycle(%)
40
40
40
Usable Electrodes(ømm)
1.6-3.2
1.6-4.0
1.6-5.0
Insulation Degree
F
F
F
Protection Degree
IP21S
IP21S
IP21S
*Includes
(1) DKA-160G Welder, (1) Electrode Clamp, (1) Ground Clamp, (1) A Brush with Chipping Hammer
(1) DKA-200G Welder, (1) Electrode Clamp, (1) Ground Clamp, (1) A Brush with Chipping Hammer
(1) DKA-250 Welder, (1) Electrode Clamp, (1) Ground Clamp, (1) A Brush with Chipping Hammer
Item DIM(mm)
220x100x160
238x109x163
318x110x173
Package DIM(mm)
320x130x280
350x130x260
450x170x260
N.W
2.4
2.86
3.92
G.W
3.4
4.04
5.38
מידע נוסף
Brand Name
DEKOPRO
Rated Duty Cycle
60%
Pilot Arc Current
60A
Usage
Welding Task
Pulse Frequency
/
Model Number
DKA-200
Dimensions
238*109*163mm
Arc Current
20-200A
Input Voltage
220V-240V
Input Power
5.8KW
Efficiency
85%
Power Factor
0.93
No-load Voltage
60V
Current Range
20-200A
Duty Cycle
60%
Electrode Diameter
1.6-4.0mm
Protection Degree
IP21S
N.W.
2.84kg
